How to Make an Arrow in Illustrator

by
Read Time:5 minsLanguages:
Final product imageFinal product imageFinal product image
What You'll Be Creating

In the following tutorial, you will learn how to make an arrow in Illustrator. We'll explore three simple methods that you can use to create arrows in Illustrator.

As well as learning how to draw an arrow in Illustrator, you can try this set of vector arrows from Envato Elements. All the arrows are fully scalable and editable. Feel free to change the size and color with just a few clicks.

illustrator arrow brushesillustrator arrow brushesillustrator arrow brushes

What You'll Learn in This Tutorial

  • How to make an arrow in Illustrator using the Stroke panel
  • How to draw an arrow in Illustrator using brushes
  • How to add an arrow in Illustrator using symbols
  • How to create a double-ended arrow in Illustrator
  • How to use Illustrator arrow brushes

Follow along with us over on our Envato Tuts+ YouTube channel:

1. How to Add Arrows in Illustrator

Step 1

The most common technique that you can use to create an arrow in Illustrator is via the Stroke panel (Window > Stroke).

Any opened path can be easily turned into an arrow. Just select it, make sure that there's a stroke applied, go to the Stroke panel, and focus on the Arrowheads options.

Choose from the 39 alternatives to easily stylize the start and end points of your path and add an arrow to a line in Illustrator.

illustrator arrow headillustrator arrow headillustrator arrow head

Step 2

Click the Swap button from the Stroke panel to quickly swap the start and end arrowhead in Illustrator.

swap arrow headswap arrow headswap arrow head

Step 3

Use the Scale values from the Stroke panel to adjust the size of your start and end arrowhead in Illustrator.

scale arrow headscale arrow headscale arrow head

Step 4

Use the Align buttons from the Stroke panel to place the arrow tip at the end of the path or to extend the arrow tip beyond the end of the path.

extend illustrator arrow headextend illustrator arrow headextend illustrator arrow head

Step 5

Keep in mind that you can select arrow designs for both ends of a path to create a double-ended arrow in Illustrator.

double ended arrowdouble ended arrowdouble ended arrow

Step 6

To recolor an arrow in Illustrator, all you have to do is change the stroke color.

double ended arrow colordouble ended arrow colordouble ended arrow color

Step 7

Besides flat colors, you can also use gradients or patterns to color an arrow in Illustrator.

double ended arrow gradient patterndouble ended arrow gradient patterndouble ended arrow gradient pattern

2. How to Draw an Arrow in Illustrator

Step 1

The second method that you can use to add an arrow to a line in Illustrator is by using brushes. For this example, we'll use some built-in Illustrator arrow brushes.

Go to the Brushes panel (Window > Brushes), open the fly-out menu, and go to Open Brush Library > Arrows > Arrows_Special. This will open a collection with some arrow brushes.

Make sure that your path is selected, and simply click the desired brush from the newly opened list. Alternatively, you can select the desired brush, grab the Brush tool (B) from your toolbar, and use it to create a curved arrow in Illustrator.

Step 2

To create a double-ended arrow in Illustrator using a brush, you can use Arrow 2.21 2 from the same collection of Illustrator arrow brushes.

illustrator double ended arrow brushillustrator double ended arrow brushillustrator double ended arrow brush

Step 3

Keep focusing on your Arrows_Special collection of brushes and click the tiny arrow buttons from the bottom of the panel to move to the next collection of arrow brushes: Arrows_Standard.

illustrator arrow brushillustrator arrow brushillustrator arrow brush

Step 4

To change the color of an arrow brush, simply change the stroke color.

If you're using a scatter brush, an art brush, or a pattern brush, make sure that Colorization Method is set to Tints.

illustrator arrow brush colorillustrator arrow brush colorillustrator arrow brush color

Step 5

Move to the next collection of brushes and use one of the available pattern brushes whenever you wish to create a multi-colored arrow in Illustrator.

Obviously, you can create your own collection of arrow brushes or you could upload a set from Envato Elements. To upload a set, all you have to do is open the fly-out menu from the Brushes panel and go to Open Brush Library > Other Library and double-click your pack of brushes.

illustrator arrow pattern brushillustrator arrow pattern brushillustrator arrow pattern brush

3. How to Add Arrows in Illustrator

The third method that you can use to create an arrow in Illustrator is via the Symbols panel (Window > Symbols).

Open the fly-out menu from the Symbols panel and go to Open Symbol Library > Arrows, which will open a collection with some arrow symbols.

Simply click and drag the desired symbol to add to your design. Scale it as you wish and double-click it whenever you need to edit it.

illustrator arrow symbolillustrator arrow symbolillustrator arrow symbol

Congratulations!

Now you know how to draw an arrow in Illustrator. I hope you've enjoyed this tutorial and can apply these techniques in your future projects.

Check out Envato Elements, where you can find some great sources of inspiration to create your own set of Illustrator arrow brushes.

illustrator arrowillustrator arrowillustrator arrow

Popular Vector Arrows From Envato Elements

Envato Elements is an excellent resource for arrow designs. Here's a short list of some of the most popular collections that you can find.

Arrow Head: Pattern Brushes & Vector Arrows (AI, EPS, PNG)

Don't have the time to create your own set of arrow brushes in Illustrator? Try this impressive collection of brushes, which includes 20 pattern brushes and over 160 hand-drawn vector arrows.

illustrator arrow pattern brushillustrator arrow pattern brushillustrator arrow pattern brush

30 Arrow Icons (AI, EPS, PNG, SVG)

This pack of slim and colorful arrow icons will make your design catchy and elegant. The icons come in two different styles: colored and outline.

illustrator arrow iconillustrator arrow iconillustrator arrow icon

3D Arrows Pack (EPS, PDF, PNG, SVG)

Make your design stand out with this collection of 3D arrows. These highly customizable designs can be easily adjusted to fit your needs.

illustrator 3D arrow illustrator 3D arrow illustrator 3D arrow

Illustrator Curved Arrows (AI, EPS)

If you're in a hurry or you simply can't be bothered to learn how to make an arrow in illustrator, this small pack of Illustrator curved arrows might be the perfect solution.

illustrator curve arrowillustrator curve arrowillustrator curve arrow

100 Vector Arrows (AI, EPS)

Looking for playful and cartoonish arrow designs? Well, look no further, because this collection gives you 100 designs to choose from.

illustrator arrowillustrator arrowillustrator arrow
